Integrated Encoders
Question messageCurrent sensor manual

ApplicationSample request
EAS-006A (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-006B (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-008A (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: SSI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-008B (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: SSI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-009 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-010B (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: SSI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-013A (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: Biss-C - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-013B (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 5 - Accuracy (arcsec): ± 10 - Communication protocol: Biss-C - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-014A (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: SSI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ30.04*1.96
ApplicationSample request
EAS-015 (integrated) Product performance:
-Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3 - Accuracy (arcsec): ± 10 - Communication protocol: SSI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ52.5*φ40.5*0.8
ApplicationSample request
EAS-016 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 10 - Accuracy (arcsec): ± 20 - Communication protocol: SPI - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ34*φ18*4.3
ApplicationSample request
EAS-018 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 10 - Accuracy (arcsec): ± 20 - Communication protocol: SPI - Position Refresh Rate (kHz): 20 -Disc Size (mm): φ34*φ18*4.3
ApplicationSample request
EAS-019 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 10 - Accuracy (arcsec): ± 20 - Communication protocol: SPI - Position Refresh Rate (kHz): 20 - Disc Size (mm): φ34*φ18*4.3
ApplicationSample request
EAS-043B-D (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 6 - Accuracy (arcsec): ± 12 - Communication protocol: Biss-C - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ58*φ32*1.96
ApplicationSample request
EAS-043-D (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 6 - Accuracy (arcsec): ± 12 - Communication protocol: Biss-C - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ58*φ36*1.96
ApplicationSample request
EAS-048 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3.6 - Accuracy (arcsec): ± 15 - Communication protocol: Biss-C - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ47.5*φ25*5*1.96
ApplicationSample request
EAS-049 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ±7 - Accuracy (arcsec): ± 15 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ117*φ89*5
ApplicationSample request
EAS-050 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3.6 - Accuracy (arcsec): ± 15 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ175*φ137*10.8
ApplicationSample request
EAS-051 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 3.6 - Accuracy (arcsec): ± 15 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ195*φ161*9
ApplicationSample request
EAS-052 (integrated) Product performance:
- Effective Resolution (bit): 24 - Repeatability (arcsec): ± 12 - Accuracy (arcsec): ± 22 - Communication protocol: RS485 - Position Refresh Rate (kHz): 18 - Disc Size (mm): φ53*φ31*1.96
